Slurry Separation System
- Category： Slurry Separation System
The Slurry separation system is an oil-water separator used to separate the oil and water by gravity stratification, its main application is the separation of oily wastewater for the refinery. The unit comprises a wastewater inlet, clean water outlet, clean oil outlet, gas release ports, and waste discharge port. It is equipped with a detachable coalescer, the oily waste enters the coalescer, separates the oil and water, then the oil flows to the oil chamber, and the water flows to the water chamber. The tank design allowed the fluids to stay in the tank for a reasonable time to ensure the complete separation of oil and water. The Tank is equipped with a level meter to watch the oil and water level conveniently.
|
Model |
Max Flow Rate |
Inlet Size |
Outlet Size |
Oil outlet Size |
Sludge Chamber Volume |
Oil Chamber |
|
SS05 |
5m3/h |
2in |
2in |
2in |
57L |
15L |
|
SS08 |
8 m3/h |
3in |
3in |
3in |
113L |
23L |
|
SS11 |
11 m3/h |
3in |
3in |
3in |
152L |
30L |
|
SS16 |
16 m3/h |
4in |
4in |
3in |
250L |
45L |
|
SS24 |
24 m3/h |
4in |
4in |
3in |
250L |
45L |
|
SS32 |
32 m3/h |
4in |
4in |
3in |
250L |
57L |
|
SS43 |
43 m3/h |
6in |
6in |
4in |
345L |
76L |
|
SS54 |
54 m3/h |
6in |
6in |
4in |
427L |
95L |
|
SS65 |
65 m3/h |
6in |
6in |
4in |
