Fireshield Hydraulic Hose
- Category： Drilling Hoses
Fireshield Hydraulic Hose
Features
- Liner material: Black NBR Rubber
- Reinforcement: 4 or 6 Wire Spirals
- Cover: Flame retardant CR/Stainless steel armor
-
Operating temperature: -40℃ to +100℃ (-104 ℉ to212 ℉ )
-
Survival temperature: 800℃ (1472 ℉ ) for 5 minutes
- Hose feature: Oil resistant/High temperature resistant/Ageing resistant
-
Standard: API Spec 16D
- Couplings: NPT thread
-
Options: Quick coupling/Self - sealing union/Swivel elbow
|
I.D. |
Working pressure |
Test pressure |
Safety factor |
Min. Bend Radius |
||||
|
mm |
in |
MPa |
Psi |
MPa |
Psi |
WP |
mm |
ft |
|
6 |
1/4 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
130 |
|
|
8 |
5/16 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
140 |
0.46 |
|
10 |
3/8 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
160 |
0.52 |
|
13 |
1/2 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
210 |
0.69 |
|
16 |
5/8 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
260 |
0.85 |
|
19 |
3/4 |
34.5 |
5000 |
51.75 |
7500 |
2.5 |
280 |
0.92 |
|
25 |
1 |
34.5 |
5000 |
103.5 |
15000 |
2.5 |
360 |
1.18 |
|
32 |
1-1/4 |
34.5 |
5000 |
103.5 |
15000 |
2.5 |
460 |
1.51 |
|
38 |
1-1/2 |
34.5 |
5000 |
103.5 |
15000 |
2.5 |
560 |
1.84 |
|
51 |
2 |
34.5 |
5000 |
103.5 |
15000 |
2.5 |
700 |
2.29 |
